The PowrMover Q-mover (2018 - 0) is for caravans with single axle caravans. The electronics have a softstart and stopfunction. This makes manoeuvring the caravan gently and has less effect on the chassis. Manoeuvring is done with a remote control (868 MHz) with push buttons. You can turn the caravan around the axle.
Technic
This mover has an operation with comfort. Thus making it possible to adjust the caravan a little left or right while manoeuvring forwards and backwards. The swiveling of the rollers towards the tire is fully automatic with the pressure on the tires controlled by the electronics.
The pressure builds up to 6900 Nm. The distance traveled when swiveling is 4 cm. De rollen staan ongeveer 2 cm van de band afgesteld, de druk van de rol in de band is dus maximaal 2 cm. The actuator motor automatically stops as soon as the pressure is sufficient or as soon as the mover has been pushed fully forward. In case of a completely discharged or defective battery, the mover can easily be removed from the beltwith an included special key. On the integrated indicator can be read if the mover is correctly engaged against the tires. The mover has a worm wheel transmission that prevents the caravan from rolling back on a slope.
The actual weight of the mover itself (our measurement) without battery is approximately 32 kg. The mover is relatively low in weight.
